Configuring promotion flows and triggers

Configure flows and triggers to orchestrate product promotions through Promotion Flows

Through Promotion Flows for Products, you can automate and control the promotion of applications from one environment to another. Promotion Flows define the steps and criteria for moving applications through different stages of deployment.

You can select multiple Promotion Flows for a product, and customize the conditions for triggering each of the selected flows to automate and control how applications are promoted.

Benefits of configuring Promotion Flows

• Multiple flows Configure multiple Promotion Flows to orchestrate promotions for the product in accordance with the deployment requirements. Promotion Flows are predefined by account administrators for the account. If the Flow you require is not available, contact your administrator.

• Custom trigger conditions Define specific trigger conditions for each Promotion Flow to tailor automated promotion based on the product’s unique deployment requirements.
  For example, configure the trigger to launch the hotfix flow whenever a commit message contains the phrase hotfix.

• Prioritization Order the Promotion Flows in the list to define the priority you need.

For how to instructions on configuring Promotion Flows, see Configure Promotion Flows.

Promotion Flow CRD

As with other GitOps entities, you can configure Promotion Flow settins in either Form or YAML modes.

Once configured and committed, these settings are saved as a CRD (Custom Resource Definition) within the Shared Configuration Repository in the GitOps Runtime selected as the Configuration Runtime. The path in the Shared Configuration Repo is <gitops-runtime>/<shared-configuration-repo>/resources/configuration/promotion-flows/.
See Shared Configuration Repository and Designating Configuration Runtimes).

To configure directly in YAML, refer to our Promotion Flow CRD for the syntax requirements and descriptions.

Examples of trigger conditions for Promotion Flows

Trigger conditions allow you to determine when and how to trigger the Promotion Flows for the product.

Let’s review a few flows and the trigger conditions you would configure for these.

Hotfix Promotion Flow

The Hotfix flow is designed for urgent fixes that need to be deployed quickly, typically to address critical bugs.

Trigger condition	Setting
	Property	commitMessage
	Operator	In
	Values	hotfix patch

The Hotfix flow is triggered when the commit message contains either hotfix or patch. This ensures that only critical changes labeled as hotfixes or patches trigger the flow.

Feature branch Promotion Flow

The Feature branch flow is designed for promoting new features from development to testing/staging environments.

Trigger condition	Setting
	Property	gitRevision
	Operator	In
	Values	feature/*

The Feature branch flow is triggered when the Git revision matches a feature branch pattern (feature/*). This ensures that only feature branches are promoted to the testing environment.

Multi-region Promotion Flow

The Multi-region flow is designed to first deploy to multiple regions, servinv as staging environments for example, for validation before the final deployment to production.

Trigger condition	Setting
	Property	gitRevision
	Operator	In
	Values	staging-*

The Multi-region flow is triggered when the Git revision matches a staging branch pattern, for example, staging-west, staging-east.
After successfully deploying in these regions, the flow can then proceed to deploy in the production environment.

Production-exclusion Promotion Flow

The Production-exclusion flow is designed to ensure that certain changes, such as experimental features or work-in-progress branches, are not deployed to the production environment.

Trigger condition	Setting
	Property	commitMessage
	Operator	NotIn
	Values	wip do-not-deploy experimental

The Production-exclusion flow is triggered only when the commit message does not contain wip, experimental, or do-not-deploy. This ensures that changes labeled with these terms are excluded from being promoted to production, preventing unfinished or unstable features from being deployed.

Rollback Promotion Flow

The Rollback flow is designed to rollback changes when an issue is detected in production.

Trigger condition	Setting
	Property	commitMessage
	Operator	In
	Values	revert rollback

The Rollback flow is triggered when the commit message contains revert or rollback, ensuring that the flow is only triggered for rollback operations.
